| C892FSP-K9 Specification |
| Cable |
| Connectivity Details Type | Network cable |
| Connectivity Details Length | 6 ft |
| Cable Details |
| Included Qty | 1 |
| Capacity |
| Type | Connection / user qty |
| Value | 50 |
| Dimensions & Weight |
| Width | 12.7 in |
| Depth | 9.8 in |
| Height | 1.7 in |
| Environmental Parameters |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 85% (non-condensing) |
| Flash Memory |
| Installed Size | 256 MB |
| Max Supported Size | 256 MB |
| Header |
| Compatibility | PC |
| Manufacturer | Cisco Systems |
| Packaged Quantity | 1 |
| Product Line | Cisco |
| Model | 892FSP |
| Brand | Cisco |
| Interface Provided |
| Interface | Ethernet 10Base-T/100Base-TX/1000Base-T |
| Type | USB 2.0 |
| Qty | 1 |
| Connector Type | 4 pin USB Type A |
| Miscellaneous |
| Compliant Standards | AS/NZ 3548 Class B, AS/NZS 60950-1, CS-03, CSA 22.2 No. 60950, EN 60555-2,
EN55022 Class B, EN55024, IEC 60950-1, UL 60950-1, VCCI-II |
| Authentication Method | RADIUS, TACACS+ |
| Networking |
| Type | Router |
| Connectivity Technology | Wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Protocol | CLI, HTTP, SNMP 3, SSH, Telnet |
| Compliant Standards | IEEE 802.1ag, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3ah |
| Status Indicators | Port status, Power |
| Features | Access Control List (ACL) support, Class of Service (CoS), Class-Based Weighted Fair
Queuing (CBWFQ), DHCP client, DHCP relay, DHCP server, DiffServ support,
DNS proxy,
IGMP snooping, Intrusion Prevention System (IPS), IPv6 support,
Link Fragmentation and
Interleaving (LFI), Low-latency queuing (LLQ), MAC address filtering, NAT support,
Quality of Service (QoS), RADIUS support, Spanning Tree Protocol (STP) support,
Virtual Routing and Forwarding (VRF), VLAN support, VPN support,
Weighted Fair Queuing (WFQ) |
| Network Transport Protocol | IPSec, L2TP |
| Routing Protocol | BGP, Bidirectional Forwarding Detection (BFD), EIGRP, GRE, HSRP, NHRP, OSPF, RIP-1,
RIP-2, VRRP, WCCP |
| Integrated Switch | 8-port switch |
| Form Factor | Desktop |
| WAN Ports Qty | 2 |
| Key Features | USB port, VPN support |
| OS Provided |
| Type | Cisco IOS Advanced IP services |
| Power Device |
| Frequency Required | 50/60 Hz |
| Power Provided | 60 Watt |
| Nominal Voltage | AC 120/230 V |
| Type | External power adapter |
| RAM |
| Installed Size | 512 MB |
| Max Supported Size | 1 GB |
| Service |
| Support Details Type | Limited warranty |
| Support Details Full Contract Period | 1 year |
| Service & Support |
| Type | 1 year warranty |
