HID Signo Keypad Reader 40K

Contactless smartcard keypad reader – multi-technology, mobile ready, wall switch mount

Key Features

  • Highly Versatile -Support for the widest range of credential technologies, including HID Mobile Access via native Bluetooth and Near Field Communication (NFC) capability. Also features Apple’s Enhanced Contactless Polling (ECP) to support credentials in the Apple Wallet.
  • Unparalleled Performance – Ultra secure storage of cryptographic keys on certified secure element hardware, plus a new surface detection feature that allows the reader to automatically recalibrate and optimize read range performance.
  • Connected to the Future – All readers include out-of-the-box support for Open Supervised Device Protocol (OSDP) for secure bidirectional communication. Each reader is also designed to be connected and managed remotely without “sneakernet” or the need to be physically touched.


  • Make                                                            HID
  • Manufacturer                                             HID Global
  • Model code                                                  Signo Reader 40K
  • Reader Type                                                Smart Card
  • Mount Type                                                 Wall mount
  • Keypad Integrated                                      Yes
  • Read Range mm                                          40 ~ 100 mm read range
  • LED / Beep                                                   Tri-colour LED, Buzzer
  • Colour                                                            Black bezel with silver trim baseplate
  • Wiegand Interface                                       Yes
  • Electrical Specifications                              Voltage: 12 V DC
  • Physical Specifications                                 Dimensions mm: 80 x 122 x 22Weight g: 160
  • Environmental Specifications                    Operating Temp oC: -35 ~ +66 C (-31 ~ +150 F)
  • Operating Humidity %: 0 ~ 95
  • Protection                                                        IP65
